High Power Motor for DIY Electric Skateboards 245kv

245kv Motor by Radium

Designed for electric skateboarding.
Radium took everything they learnt about electric motors and worked closely with manufacturing partners to make specific improvements that take this motor to a whole new level.

Features:

• Ultra quiet FOC operation

• Ultra low rolling resistance
• Replaceable quad bearings

• Dust sealed exterior bearing
• Front mounted sensor PCB for the most reliable sensor operation
• High efficiency for maximum range
• Active cooling system
• Mesh protected air intakes.

Specifications:

• Dyno verified peak power - 8397W (245kv/48V), 7026W (205kv/48V)
• 10-20S Voltage
• 64mm diameter, 85mm length
• Curved N45UH magnets rated to 180C
• Battle hardened (magnets reinforced with additional epoxy)
• Serviceable quad NMB bearings
• 2.5mm thick steel rotor for impact protection and improved magnetic flux path
• Cooling system with mesh protected air intakes
• Front mounted PCB for best sensor performance
• Multi-core flexible Teflon hall sensor wires with 2.0mm JST connector (vesc plug & play), 40cm length
• Red 12awg silicone phase wires (30cm) with 4mm bullets
• 8mm shaft with keyway, 45mm length
• 44mm mounting pattern (adapters for 30mm Lacroix/SRB 3-Link pattern sold separately)
• Maximum operating temperature of 100C
• Each motor weighs 1.1kg.

Price is per motor.
